Specification

Working Width (mm)

2750 | 3000 | 3250 | 3500

Brush Speed

Recommended 80 to max. 120 U/min

Weight for Base Model (kg)

2265, 2338, 2426, 2525

Application

Free sweeping | Sweeping & taking up dirt

Carrier Vehicle

Wheel Loader from 12t | Tractor (front)

Collection Container Volume (L)

1060, 1155, 1250, 1350

Minimum Hydraulic Power of the Carrier Vehicle (L/min)

80

Water Spray Unit (optional)

400 litres water tank, tank filter and 12/24 volts pressure pump(direct injection of water into the main brush and rotary side brushes)

Wheels

Super-elastic solid rubber wheels Ø 446 x 122 mm with reinforced rim (4 mm)

Drive

Hydraulic drive, two powerful Gerotormotors with drive shaft Ø 32 mm, completely inside (heavy series)

Other Equipment (optional)

Hydraulic swivel device (20° to the left/right);bema Control (from 3 functions available)

Main Brush

Ø 920 mm;PPN BEE-LINE power brush with honeycomb brush rings (no PVC),toolless and stepless adjustment of the main brush via adjustment spindle
